It is a wireless presenter as a remote control , a laser pointer and portable storage device . It is tailored as a

handy-tool for presentations , teaching ,meetings ,speeches ,trainings .
It consists of two parts: transmitter and USB receiver.
I. Setup :
Plug the receiver into the USB port on your PC .The system will automatically search for the new hardware and complete the setup.

II. Function :
1.Button B Laser pointer.
2.Button A page/scroll up function.
3. Button C page/scroll down function.

III ．Technical parameters

Transmitter

Class
Class II
Class III

Techno l ogy
Infrared Frequency
Infrared Frequency

Frequency
433 . 92/315MHz
433 . 92/315MHz

Control distance
>1 5 m
>15m

Battery
AAA*2
AAA*2

Working voltage
3 V
3 V

Wavelength
532 nm
532 nm

Max output
<1mW
< 5 mW

Dimension
L=1 5.8 cm ø =1. 6 cm

(RF1601 RF1603 IR1801)
L=1 5.8 cm ø =1. 6 cm

L=1 2.1 cm H =1. 8 CMW=1.5 cm

(RF1602)



Transmitter

Operation system
Windows98．Se．Me．2000．XP． Mac OS． Linux

Compatible plug
USB 1.1 　 USB2.0

Working voltage
3 V


IV ． Warning:To avoid the laser radiation to direct eyes !
