Mr-series consist of two way full range enclosure ( MR-926 ), three way full range enclosures ( MR-935, MR-938 ), and subwoofer ( MR-918 ). All MR models are made of 18mm plywood, those cabinets are designed in a trapezoidal shape to allow two or more loudspeakers to be splayed for wide horizontal coverage. The corner protector are designed with interlocking feet so that those models of the same width and depth and can be safety stacked

Series Key Feature:
1>. Polymer diaphragm compression driver for clear sound reproduction and reliable application
2>. 100H×80V degree despersion horns for full range cabinets
3>. Passive or active optional
4>. 18mm steel grill for maximum protection of low frequency transducers
5>. Pro high frequency driver protection circuit
6>. All models are made of 18mm ultra intensity plywood
7>. Standard 35mm cup for easy connection other cabinets

Model: MR-926 two way full range speaker
Specification
* Frequency Response (±3 dB): 40 Hz - 20 kHz
* Sensitivity (1w/1m): 99 dB SPL
* Long-term SPL: 127 dB
* Maximum SPL: 130 dB
* Nominal Impedance: 8 ohms
* Power rated: 350 watts
* Peak Power handling: 700 watts
* Nominal Dispersion: 100ºH x 80ºV
* Crossover Frequency: 1.5 kHz
* Dimensions (H x W x D): 1035 mm x 714 mm x 457 mm
* Enclosure Material: 18mm polywood
* Surface Finished: black catalyzed polyurethane paint
* Grille: 1.8mm black perforated steel framed
* Net weight: 55 kg
* Low Frequency Driver: 15”, 190mm magnet
* High Frequency Driver: 2” compression driver.
* Input Connectors: Neutrik NL4MPX2

Model: MR-935 three way full range speaker
Specification
* Frequency Response (±3 dB): 40 Hz - 19 kHz
* Sensitivity (1w/1m): 100 dB SPL
* Long-term SPL: 128 dB
* Maximum SPL: 134 dB
* Nominal Impedance: 8 ohms
* Power rated: 600 watts
* Peak Power handling: 1200 watts
* Nominal Dispersion: 100ºH x 80ºV
* Crossover Frequency: 600Hz; 2.2 kHz
* Dimensions (H x W x D): 714 mm x 714 mm x 457 mm
* Enclosure Material: 18mm polywood
* Surface Finished: black catalyzed polyurethane paint
* Grille: 1.8mm black perforated steel framed
* Net weight: 43 kg
* Low Frequency Driver: 15”, 200mm magnet
* Mid Frequency Driver: 8”, 170mm magnet
* High Frequency Driver: 2” throat, 3” compression driver.
* Input Connectors: Neutrik NL4MPX2

Model: MR-938 three way full range speaker
Specification
* Frequency Response (±3 dB): 40 Hz - 19 kHz
* Sensitivity (1w/1m): 100 dB SPL
* Long-term SPL: 128 dB
* Maximum SPL: 134 dB
* Nominal Impedance: 8 ohms
* Power rated: 900 watts
* Peak Power handling: 1800 watts
* Nominal Dispersion: 90ºH x 60ºV
* Crossover Frequency: 600Hz; 2.0 kHz
* Dimensions (H x W x D): 845 mm x 714 mm x 457 mm
* Enclosure Material: 18mm polywood
* Surface Finished: black catalyzed polyurethane paint
* Grille: 1.8mm black perforated steel framed
* Net weight: 58 kg
* Low Frequency Driver: 18”, 220mm magnet
* Mid Frequency Driver: 10”, 170mm magnet
* High Frequency Driver: 3” compression driver
* Input Connectors: Neutrik NL4MPX2

Model: MR-918 single 18 inch subwooofer
Specification
* Frequency Response (±3 dB): 40 Hz - 800Hz
* Sensitivity (1w/1m): 100 dB SPL
* Long-term SPL: 129dB
* Maximum SPL: 135 dB
* Nominal Impedance: 8 ohms
* Power rated: 600 watts
* Peak Power handling: 1200 watts
* Dimensions (H x W x D): 1035 mm x 714 mm x 457 mm
* Enclosure Material: 18mm plywood
* Surface Finished: black catalyzed polyurethane paint
* Grille: 1.8mm black perforated steel framed
* Net weight: 48kg
* Low Frequency Driver: 1X18” 100mm voice coil, 220mm magnet
* Input Connectors: Neutrik NL4MPX2
